FoxESS H3-Pro 20.0 | 20kW Three-Phase Hybrid Inverter

Rated Output Power: 20,000W (20kW)
Max DC Input Power: 30,000W
Max Efficiency: 98.6%
European Efficiency: 98.2%
Dual Battery Input: For high-voltage lithium batteries
Number of MPPTs: 3 (for flexible array configuration)
Max PV Voltage: 1,000V
Start-up Voltage: 160V
Emergency Power Supply (EPS) Output: 20kW
Communication: RS485, CAN, Wi-Fi, Fox Cloud support
Remote Monitoring: App + web portal
Integrated DC Switch and AFCI Protection
G99 / G100 Certified
Protection Class: IP65 (indoor & outdoor use)
Dimensions: Approx. 700 × 480 × 230 mm
Weight: Approx. 55–60 kg
