JA Solar 585W N-Type Bifacial Panel

The JA Solar 585W N-Type Bifacial Panel delivers next-level performance with cutting-edge N-Type TOPCon technology, bifacial generation, and ultra-low degradation—ideal for commercial, industrial, and large-scale solar power systems.

• Brand: JA Solar
• Model: JAM72D40-585/GB
• Power Output: 585W
• Cell Technology: N-Type TOPCon Monocrystalline
• Bifacial Gain: Up to 80% additional rear-side power
• Module Efficiency: 22.9% (Front Side)
• No. of Cells: 144 Half-Cells (6×24)
• Dimensions: 2278 × 1134 × 30mm
• Weight: 32.6 kg
• Front/Back Glass: Dual 2.0mm Tempered Glass (AR-coated)
• Frame: Anodized Aluminum Alloy
• Junction Box: IP68, Split Design
• Connector Type: MC4 or Compatible
• Power Tolerance: 0 ~ +5W
• Operating Temperature: -40°C ~ +85°C
• Wind/Snow Load: 2400 / 5400 Pa
